Pumicite

A Vulkan rendering framework for Bevy that preserves direct, low-level GPU control while using Bevy's ECS as the backbone for scheduling, concurrency, and resource management.

Why Pumicite?

Bevy's built-in renderer uses wgpu, which prioritizes safety over giving you direct control of the GPU. Pumicite takes a different approach: it provides you with the essential tools to write an efficient and flexible Vulkan application, but leaves enough room for you to fine tune your application and make the best out of Vulkan.

Instead of building a render graph abstraction on top of Bevy, it treats Bevy systems as render graph nodes and system ordering as node dependencies. A schedule build pass automatically handles command buffer allocation, barrier insertion, and queue submission.

You write Bevy systems that record Vulkan commands. Pumicite takes care of the rest.

use bevy::prelude::*;
use bevy_pumicite::prelude::*;

fn main() {
    let mut app = App::new();
    app.add_plugins(bevy_pumicite::DefaultPlugins);
    app.add_systems(PostUpdate, clear.in_set(DefaultRenderSet));
    app.run();
}

fn clear(
    mut swapchain_image: Query<&mut SwapchainImage, With<bevy::window::PrimaryWindow>>,
    mut state: SubmissionState,
    time: Res<Time>,
) {
    let Ok(mut swapchain_image) = swapchain_image.single_mut() else { return };

    state.record(|encoder| {
        let Some(current) = swapchain_image.current_image() else { return };
        let current = encoder.lock(current, vk::PipelineStageFlags2::CLEAR);
        encoder.use_image_resource(
            current, &mut swapchain_image.state,
            Access::CLEAR, vk::ImageLayout::TRANSFER_DST_OPTIMAL,
            0..1, 0..1, false,
        );
        encoder.emit_barriers();

        let hue = (time.elapsed_secs() * 72.0) % 360.0;
        let color: bevy::color::Srgba = bevy::color::Hsla::new(hue, 0.8, 0.5, 1.0).into();
        encoder.clear_color_image_with_layout(
            current,
            &vk::ClearColorValue { float32: color.to_f32_array() },
            vk::ImageLayout::TRANSFER_DST_OPTIMAL,
        );
    });
}

Key Features

• System-as-Render-Graph -- Bevy systems are render graph nodes. The ECS scheduler handles dependency tracking, mutual exclusion, and parallel execution. A ScheduleBuildPass transforms system sets into vkQueueSubmit calls.

• Coroutine-as-Render-Graph -- Record commands with Rust async/await, or ideally coroutines when it stabilizes. Yield points emit barriers and enable cross-future barrier merging.

• GPUMutex -- Timeline semaphore-based cross-queue synchronization. Lock a resource on a command encoder and semaphore waits are inserted automatically. Safe deferred cleanup via a recycler thread.

• Resource State Tracking -- Declare how you're about to use a resource and the framework computes the minimal pipeline barrier. You control the tracking granularity and where state is stored.

• Bindless Rendering -- Global descriptor heaps using VK_EXT_mutable_descriptor_type. All resources in one array, accessed by index through push constants. No descriptor set switching between draws. Forward compatible with VK_EXT_descriptor_heap.

• Dynamic Rendering -- No legacy VkRenderPass or VkFramebuffer. Attachments are specified inline when you begin rendering.

Requirements

• Rust: Nightly
• Vulkan: 1.2+ with VK_KHR_synchronization2 and VK_KHR_timeline_semaphore
• Platform: Windows, Linux, macOS (via MoltenVK or KosmicKrisp)

Getting Started

With Bevy

[dependencies]
bevy = { version = "0.17.0-dev", default-features = false, features = [
    "bevy_winit", "bevy_asset", "multi_threaded"
] }
bevy_pumicite = "0.1"

[patch.crates-io]
# Unfortunately, we need to fork bevy for now. The goal is to eventually upstream all the changes.
bevy = { git = "https://github.com/dust-engine/bevy", branch = "release-0.17.3" }

fn main() {
    App::new()
        .add_plugins(bevy_pumicite::DefaultPlugins)
        .run();
}

Without Bevy

[dependencies]
pumicite = "0.1"

use pumicite::prelude::*;

let (device, mut queue) = Device::create_system_default().unwrap();
let allocator = Allocator::new(device.clone()).unwrap();

Examples

Run examples with:

cargo run --example <name>

Example	Description
basics	Headless image clear -- no window, no Bevy
clear	Window that clears to a cycling color
triangle	Graphics pipeline with dynamic rendering
mandelbrot	Interactive compute shader with push descriptors
bindless	Compute shader using bindless descriptor indexing
sky_atmosphere	Precomputed atmospheric scattering LUTs
mesh_shading	Mesh shader pipeline with dynamic rendering
mesh_shader_culling	Mesh shader culling with egui debug UI
egui	egui integration for immediate-mode debug UIs
gltf	glTF model loading with PBR shading

Crates

Crate	Description
pumicite	Core Vulkan wrapper -- device, commands, sync, memory, pipelines
bevy_pumicite	Bevy integration -- plugins, submission sets, asset loaders, swapchain
pumicite_egui	egui integration for debug UIs
pumicite_scene	Scene and glTF loading

Tutorial

The tutorial walks through Pumicite from the ground up:

1. Overview -- Motivation, philosophy, and key concepts
2. Getting Started -- Device creation and first command buffer
3. Resource Management -- Buffers, images, and memory allocation
4. Synchronization -- Barriers, resource state tracking, and GPUMutex
5. Bevy Integration -- Plugins, submission sets, and the ECS render graph
6. Compute -- Compute pipelines, dispatch, and multi-pass workflows
7. Rendering -- Dynamic rendering, graphics pipelines, and draw commands
8. Bindless -- Descriptor heaps and bindless resource indexing

License

Dual-licensed under MIT or Apache 2.0.

---

Note: Pumicite is under active development. We offer no API stability guarantee until 1.0 release. Use at your own risk.
